Understanding Sticking Tablets: Causes and Remedies

Understanding Sticking Tablets: Causes and Remedies
stick tablet (4)

What is tablet sticking and picking?

Tablet sticking and picking are issues encountered during tablet production processes. Sticking is when tablets cling to the punch’s surface or die, making it difficult to remove them. Picking, on the other hand, happens when a portion of the tablet is left behind on the punch, leading to tablet weight and size inconsistency. These issues are some of the most common challenges tablet manufacturers face today.

stick tablet

Causes of Sticking and Picking

Several factors can lead to tablet sticking and picking. These include:

Formulation factors include the type of excipients used, the amount of lubricants, and the compatibility of the ingredients.

Tablet compression parameters include applied pressure, turret speed, and die wall lubrication.

Environmental factors such as temperature and humidity.

Machine-related factors such as tooling condition, press speed, and alignment.

Material-related factors such as particle size, moisture content, and flowability.

Effects of Sticking and Picking on Tablet Production

The consequences of tablet sticking and picking are numerous and costly. These problems can result in machine downtime, production delays, and increased product rejection rates. These issues can also lead to batch-to-batch variability, harming product efficacy and patient safety.

Preventing Sticking and Picking

To prevent tablet sticking and picking, it is essential to understand the root causes of the problem and implement appropriate measures during tablet production. Here are some best practices for avoiding sticking and picking:

Formulation optimization: Use optimal amounts of lubricants and choose excipients wisely to reduce incompatibilities.

Machine Optimization: Keep punch and die tools clean, well-lubricated, and properly aligned.

Environmental Conditions: Maintain temperature and humidity within recommended limits.

Material Handling: Handle materials carefully to prevent damage to particle size, moisture content, and flowability.

Recommended Reading: Tablet Press Machine Information

Remedies for Sticking and Picking

Despite the best preventative measures, sticking and picking may still occur. Here are some remedial measures that manufacturers can take to address these issues:

Relubrication: Add more lubricant to the tablet bed and increase the die wall lubrication.

Re-Compression: Recompress the tablets to remove the picking marks or stains.

Additives: Add magnesium stearate or other lubricants to the formula or modify its amount.

Common Sticking and Picking Problems Faced by Tablet Manufacturers

Joint sticking and picking challenges in tablet production include insufficient lubrication, incorrect or incompatible formulation ingredients, tooling and machine wear and tear, and handling and storage issues. Manufacturers must proactively identify the cause of sticking and picking and develop robust preventative measures to ensure optimal tablet production.

How does tablet compression affect sticking?

Pharmaceutical researchers constantly strive to improve tablet manufacturing processes and reduce production costs. Tablet compression is essential in producing various pharmaceutical products, including over-the-counter and prescription drugs. It involves compacting powders into a solid, dense tablet by applying high pressure. However, one of the challenges associated with tablet compression is sticking. Sticking refers to the undesirable adhesion of powder particles to the tablet press equipment. It can lead to tablet weight and dimension variations, lower tablet quality, and potentially affect the drug’s efficacy.

stick tablet

Importance of Tablet Compression

Tablet compression is crucial in the drug manufacturing to ensure consistent dosages and high-quality products. It guarantees proper drug uptake, precise delivery, and controlled drug release. In addition, tablet compression enables easy handling, storage, and transportation of pharmaceutical products. Poorly compressed tablets may crumble, chip, or break during handling, leading to inaccurate dosing and drug delivery.

Effects of Compression Force on Sticking

Compression force is a critical parameter in tablet production. It refers to the pressure applied to the powder during compression and is a crucial factor influencing sticking. Too much stress can increase sticking, while too little pressure can result in poorly compressed tablets. The bonding cause is rooted in the interparticle forces of the powder mixture. When subjected to high compression pressure, these forces get more muscular, increasing interparticle adhesion and stickiness. Thus, balancing the compression force and sticking is essential to obtain the desired outcomes.

Optimizing Compression to Reduce Sticking

Optimizing compression parameters such as compression force, tablet diameter, and tablet thickness can significantly reduce sticking. Studies have shown that lowering compression force or increasing tablet diameter and thickness can reduce the interparticle forces, thereby minimizing sticking. A lower compression force can enhance tablet hardness while reducing sticking. Hence, an optimal compression force can be achieved by conducting experiments with different levels of compression force for a given powder formulation.

Recommended Reading: Choosing The Best Tablet Form: A Comprehensive Guide

Role of Dwell Time in Preventing Sticking

Dwell time is when the powder is in contact with the tablet press machine during compression. The period-dwell time duration influences the tablet’s final hardness and sticking tendency. A shorter dwell time can reduce sticking since the powder stays in the compression zone less, reducing the adhesive forces. Some tablet production processes incorporate measures to reduce dwell time, such as increasing press speed and using multiple punch heads.

Impact of Moisture Content on Tablet Sticking

Moisture content is a critical factor in tablet compression. High moisture content can reduce the strength of the powder particle bonds and lead to a higher tendency for sticking. Moisture can also cause softening of the powder and create difficulties in separation from the punch head, leading to production challenges. Properly handling and storing raw materials and finished products can prevent water absorption and thus maintain the necessary moisture content.

What role does tablet tooling play in sticking?

The manufacturing of tablets is a complex process that requires precision and attention to detail to achieve high-quality results. One of the most common issues encountered during tablet production is sticking, where the tablet material adheres to the tooling and causes defects. This issue leads to production delays, increased costs, and lower product quality, negatively impacting the manufacturer’s reputation.

Recommended Reading: Keep Your Tablet Press Machine In Top Condition

Understanding tablet tooling

Tablet tooling is the mechanical device used to produce tablets by compressing powders or granules into the desired form. It comprises a punch, which forms the tablet’s top and bottom, and a die, which shapes the tablet’s sides. The energy and die are essential parts of the tablet compression machine, and their design plays a significant role in avoiding sticking problems.

The shape of the tablet is a crucial factor in determining sticking risks. The tablet’s surface should be smooth, and the edges should be well-defined to prevent damage caused by friction or binding. Any irregularities on the surface of a tablet lead to an increased risk of sticking—research indicates that leveraging a shallower angle on the punch tip can improve tablet formation, reducing the risk of sticking.

How tablet shape affects sticking

The punch influences the tablet’s shape and die’s design, determining the thickness, hardness, and form. The punch tip design plays a crucial role in preventing sticking. The ideal punch tip design has a shallow angle to reduce the risk of excessive powder compaction, reducing tablet binding and sticking. Punch tip repairs and replacements should be made whenever there is wear and tear to avoid unwanted defects.

Importance of punch tip design in reducing sticking

The importance of punch tip design lies in its ability to reduce the risk of sticking. Punch tip repairs and replacements should be made consistently to avoid producing unwanted defects. Manufacturers must maintain punch tips as part of the routine machine maintenance.

Installing proper coatings on tablet tooling

Proper coatings on tablet tooling can improve materials’ flow and reduce the risk of sticking. Coatings such as Teflon-like materials, diamond-like carbon coatings (DLC), and nanocomposite coatings enhance the surface properties of the tablet tooling, providing a consistently high-quality surface and reducing the risk of defects. Manufacturers should consider the material properties of the tablet and the coating used to ensure optimal results.

Using lubricants to prevent sticking

Lubricants act as a protective barrier in the tablet pressing process, reducing friction between the tooling and the tablet material. Correctly applied fats can decrease the risk of damage to the tablet surface during compression, reducing the risk of sticking. Lubrication can be applied through various methods, such as spray or powder, depending on the type of tablet material.

What are the major problems faced in tablet coating?

One of the most significant challenges in tablet coating is achieving a uniform coating thickness. This is essential to ensure that each tablet receives the correct dose of medication. Achieving an even layer can be difficult due to the complex shape of the tablets, which can cause uneven coating distribution.

Another significant issue is the potential for coating defects, such as air entrapment, cracking, peeling, mottling, or erosion of the tablets. Various factors, including the formulation, process parameters, equipment, and environmental conditions can cause these defects.

Common Defects Caused by Tablet Coating

Air entrapment is a common defect when air gets trapped between the tablet surface and the coating. This issue can result in an uneven surface or holes in the layer. This can cause the medication to be released too quickly or impact its efficacy.

Cracking is another common defect that can occur during the coating process. This issue happens when the coating material cracks and separates from the tablet. Cracking can impact the tablet’s aesthetic appeal as well as its efficacy.

Peeling is a coating defect that can occur if the coating material fails to adhere to the tablet’s surface. Peeling can expose the medication to the environment, compromising the efficacy of the tablet.

Reducing Sticking During the Coating Process

One of the most significant challenges in tablet coating is reducing sticking between the tablets during the coating process. When tablets stick together, they can impact each other’s coating thickness, causing uneven layers and compromising the medication’s efficacy. One way to reduce sticking is by using anti-stick coating materials or adding lubricants to the formulation to prevent adhesion.


The Role of Formulation in Coating-Related Sticking

The formulation plays a crucial role in coating-related sticking. Factors such as particle size and shape, as well as the composition of the coating solution, can directly impact the likelihood of sticking. Fine particle size and unstable formulations may result in tablet sticking during the coating process. Thus, selecting a stable formulation and an appropriate coating material is vital to reduce sticking.

Importance of Selecting the Right Coating Materials

A wide range of coating materials is available in the pharmaceutical industry, including film-coating materials, aqueous polymer dispersions, and sugar-coating materials. Choosing the suitable coating material is essential to achieve the optimal coating for the medication to prevent defects and increase stability. Different coating materials can impact the release profile of the drug, so it’s crucial to choose the suitable material for the intended application.

Best Practices for Efficient Tablet Coating

To achieve efficient tablet coating, it is essential to ensure the coating process is well-controlled and optimized. The coating equipment’s temperature, humidity, and airflow should be carefully monitored and controlled to prevent defects. Additionally, it is crucial to select the appropriate process parameters and equipment, including the coating solution’s viscosity, the spray rate, and the atomization pressure.

How can tablet press design impact stick?

Tablet press design can significantly impact sticking, one of the most frustrating issues in pharmaceutical manufacturing. Piercing is the adherence of tablet material to the die wall or punch face, which can result in gaps or defects in the final product.

Understanding the role of tablet press in sticking

The tablet press plays a critical role in determining whether tablets will stick. The compression force, roll pressure, granule properties, and turret speed are all factors that can influence sticking. Additionally, the tooling material and surface roughness can increase or decrease the tendency of the tablet material to stick.

Optimizing punch surface properties to reduce sticking

Optimizing punch surface properties is essential for minimizing sticking. The surface roughness, tool materials, and coatings can all impact sticking. It is recommended to use punch surfaces that are as smooth as possible to reduce friction and sticking. Also, choosing high-quality materials, such as tungsten carbide or ceramic coatings, can decrease the likelihood of sticking.

Effect of lubrication in tablet compression

Lubrication is a common technique used to reduce sticking. It involves adding a lubricant, such as magnesium stearate or stearic acid, to the tablet formulation. This lubricant reduces friction between the die wall or punches face and the tablet material, preventing sticking. However, it is essential to note that over-lubrication can have adverse effects, such as reducing tablet hardness, so the amount of lubricant used should be carefully controlled.

Choosing the right tablet press to minimize sticking

Choosing the right tablet press is crucial for reducing sticking. Factors like tooling design, compression force, and turret speed depend on the tablet formulation and material properties. It is essential to select a tablet press appropriate for the specific product and ensure the equipment is well-maintained.

Addressing common issues with tablet press design

Common issues with tablet press design include wear and tear on the tooling, insufficient or uneven compression force, and incorrect die specifications. These issues can be addressed by performing regular maintenance on the equipment, monitoring compression force during operation, and ensuring that the correct specifications are used when ordering new tooling.

Recommended Reading: Single Punch Tablet Machine Information

Frequently Asked Questions:

sticking tablet

Q: How does lubrication help reduce sticking in tablet manufacturing?

A: Lubrication helps reduce sticking by preventing the tablets from sticking to the punch face.

Q: What is sticking or picking in tablet manufacturing?

A: Sticking or picking refers to when the tablets adhere to the punch face, leading to defects.

Q: What is one of the significant problems tablet manufacturing companies face?

A: One of the significant problems tablet manufacturing companies face is sticking or picking pills during the tableting process.

Q: How do tablet punches cause sticking?

A: The tablet punches can cause sticking if the surface finish is not optimal or there is inadequate lubrication.

Q: What are some standard terms related to sticking in tablet manufacturing?

A: Some standard terms related to sticking in tablet manufacturing include tableting, sticking propensity, tablet defects, and picking.

Q: What can cause sticking in tablet manufacturing?

A: Several factors can cause sticking in tablet manufacturing, such as inadequate lubrication, poor surface finish of punches, and certain APIs (Active Pharmaceutical Ingredients) having a higher propensity for sticking.

Q: What is picking in tablet manufacturing?

A: Picking is a specific type of sticking where the tablet material is prone to adhering to the punch face and forming defects on the tablets.

Q: How can tablet manufacturing companies stop sticking from occurring?

A: Tablet manufacturing companies can take measures such as optimizing the surface finish of punches, using suitable lubricants, and adjusting the formulation to minimize the sticking propensity of the tablets.

Q: How can I ensure my tablets don’t stick during manufacturing?

A: To prevent sticking, ensure you’re using the appropriate lubrication, optimizing the surface finish of punches, and adjusting the formulation if necessary.
